We are professional led display factory. we had wide cooperation with Cree, Epistar, Silan. we use 2020 black face leds for ph3,ph4,ph6. we also doing ph8,ph10 with great price.And with excellent enginers team. you can get what you truelly want from here.

And also, we have been years working on led technical. we have above 95% auto producing machine line, include SMD banding machine, SMD soldering machine, Wave mounting machine. all this will help you win out from the competition.

PH4 specifications:

Items		P3.91 3 in 1 full color
Ledmodule	Pixel structure	SMD2020 3 in1 LED
	Pixel pitch (mm)	4
	Module resolutions	64×64
	Module size (mm)	256×256
	Module weight（kg）	0.1
	Max consumption（W）	10.5W
Unitboardandcabinet	Module array（W×H）	2×2
	Cabinet resolutions	128×128
	Cabinet size（mm）	512×512
	Cabinet square（㎡）	0.25
	weight（kg/cabinet）	6.5
	Pixel density（点/㎡）	62500
	Cabinet uniform（mm）	0.2
